【DK-SOC-1SSX-L-A】Intel? Stratix? 10 SX SoC Development Kit
- 產品型號： DK-SOC-1SSX-L-A
- 產品品牌： TERASIC友晶科技/Intel FPGA
- 產品規格： 1SX280LU2F50E1VG
- 產品價格： 歡迎咨詢采購，量多優惠多，提供完善的售后保障和支持！
- 咨詢熱線：18062095810
The Intel® Stratix® 10 SoC Development Kit offers a quick and simple approach for developing custom ARM* processor-based SoC designs. The Stratix 10 SoCs offer full software compatibility with previous generation SoCs, a broad ecosystem of ARM software and tools, and the enhanced FPGA and digital signal processing (DSP) hardware design flow.
You can use this development kit to:
Evaluate Stratix 10 SoC device features and performance
Begin development of your hardware and software design
Use as a platform for target reference designs, OS/BSP, and tools
| Hardware |
|---|
|
| Software1 |
|---|
|
Download and unzip Stratix 10 SoC Development Kit installer first. Install the Stratix 10 SoC Board Test System.A one-year license for Quartus® Prime design software is available upon purchase of the kit. License activation instructions and FAQs .
| No | 產品名稱 | 售價(RMB) |
|---|---|---|
| 1. | Stratix 10 SX SoC Development Kit (Production)
產品編號: T0617  重量: 7,500g | xxx |
| 2. | Stratix 10 SX SoC Advanced Security Development Kit (Production)
產品編號: T0644 重量: 7,500g | xxx |
Documents
| 標題 | 版本 | 檔案大小(KB) | 新增日期 | 下載 |
|---|---|---|---|---|
| Stratix 10 SX SoC Package Installer |
ES (18.0 or higher)  | 2018-11-23 |  | |
| User Guide (ES Edition) |
ES Edition | 2018-11-23 |  | |
| Board Schematic | | 2018-11-23 |  |
Daughter Card Files
| 標題 | 版本 | 檔案大小(KB) | 新增日期 | 下載 |
|---|---|---|---|---|
| IO48 OOBE Daughter Card | Rev A | 2018-11-23 | | |
| IO48 NAND Daughter Card | Rev A | 2018-11-23 | | |
| SDM QSPI Boot Flash Daughter Card | Rev A | 2018-11-23 | | |
| SDM NAND Boot Flash Daughter Card | Rev A | 2018-11-23 | | |
| SDM MicroSD Boot Flash Daughter Card | Rev A | 2018-11-23 | | |
| SDM eMMC Boot Flash Daughter Card | Rev A | 2018-11-23 | |
