【DK-SI-1STX-E-A】英特爾?Stratix?10 TX信號完整性開發套件

  • 產品型號： DK-SI-1STX-E-A
  • 產品品牌： TERASIC友晶科技/Intel FPGA
  • 產品規格： 1ST280EY2F55E1VG
  • 產品價格： 歡迎咨詢采購，量多優惠多，提供完善的售后保障和支持！
  • 咨詢熱線：18062095810

The Intel® Stratix® 10 TX Signal Integrity (SI) Development Kit offers a complete design environment that includes both hardware and software for developing Intel Stratix 10 TX FPGA designs.

You can use this development kit to:

  • Evaluate transceiver performance up to 28.3 Gbps for H-Tile and 58 Gbps for E-Tile

  • Generate and check pseudo-random binary sequence (PRBS) patterns

  • Dynamically change differential output voltage (VOD) pre-emphasis and equalization settings to optimize tranceiver performance for your channel

  • Perform jitter analysis

  • Verify physical medium attachment (PMA) compliance to PCI Express* (PCIe*), 10G/25G/50G/100G/200G/400G Ethernet, and other major standards


Hardware

  • Stratix 10 TX Signal Integrity development board wth Stratix 10 TX FPGA

  • FPGA mezzanine card (FMC) and loopback card

  • AC adapter power cables

  • Ethernet and USB cables



Software1

  • Design examples

  • Board Test System (BTS) design

  • Documentation

  • Intel Stratix 10 TX SI Development Kit User Guide

  • Board design files

  • Design software2

  • Intel Quartus Prime software (required)

  • Nios® II processor (optional)

  • Intel FPGA intellectual property (IP) library (optional)

  • Mentor Graphics® ModelSim*-Intel FPGA software (optional)

  1. Download and unzip the Intel Stratix 10 TX SI Development Kit installer first. Install the Intel Stratix 10 TX SI BTS.

  2. A one-year license for Intel Quartus® Prime design software is available upon purchase of the kit. License activation instructions and FAQs .

Documents

標題 版本 檔案大小(KB) 新增日期 下載
Stratix 10 TX Signal Integrity Installer Package ES (18.0)    2018-11-23
User Guide ES Edition    2018-11-23
Quick Start Guide ES Edition    2018-11-23
Board Schematic ES Edition    2018-11-23
