【DK-DEV-10CX220-A】Cyclone 10 GX FPGA Development Kit
- 產品型號： DK-DEV-10CX220-A/C10GFP（Part No:T0556）
- 產品品牌： TERASIC友晶科技/Intel FPGA
- 產品規格： Cyclone 10 GX FPGAs
- 產品價格： 歡迎咨詢采購，量多優惠多，提供完善的售后保障和支持！
- 咨詢熱線：18062095810
If you are evaluating Intel® Cyclone® 10 GX FPGAs or already at the design concept stage, Intel has a complete ecosystem to support your design, which includes development kits, software, intellectual property (IP), design examples , Design Solutions Network partners , and Engineer-to-Engineer videos to reduce your time to market.
The Intel Cyclone 10 GX FPGA Development Kit is an ideal starting point for applications, such as embedded vision , factory automation , or video connectivity evaluation or concept proving.
With this development kit, you can:
Develop designs for Intel Cyclone 10 GX FPGAs
Develop and test PCI Express* (PCIe*) 2.0 designs using the PCI-SIG*- compliant development board
Direct connection via USB 3.1 Type C, small form-factor pluggable (SFP+), and RJ-45 connectors
Develop modular and scalable designs by using direct connection or via the FPGA mezzanine card (FMC) connector to support protocols, such as USB 3.1 Gen2, GigE Vision,12G serial digital interface (SDI) , DisplayPort , HDMI , JESD204B , Serial Rapid I/O*, Common Public Radio Interface (CPRI), and IEEE 1588
For a complete list of IP cores from both Intel and our partners, use the IP search engine .
For more information on Intel Cyclone 10 GX FPGAs, visit the Intel Cyclone 10 GX FPGA Overview page .
| No | 產品名稱 | Feature | 售價(RMB) |
|---|---|---|---|
| 1. |
[C10GFP] Intel® Cyclone® 10 GX FPGA Development Kit
產品編號: T0556  重量: 3,500g | xxx |
| 標題 | 版本 | 檔案大小(KB) | 新增日期 | 下載 |
|---|---|---|---|---|
| User Guide |
1  | 2018-01-05 |  | |
| Schematic |
A | 2018-01-05 | | |
| Kit Collateral (zip) |
A | 2018-01-05 |  |
